vga wiring for Packard Bell slimview 517?

I have a Slimview 517 in good condition but the vga(sub-d) connector was cut off en lost during transport. But i need the color diagram to mount a new connector. Anyone who owns the same monitor could provide this info. I would be gratefull.
Thabks,
Carlos

Carlos
December 2006

Packard Bell Packard Bell Slimview 517 Computers, Computer Monitors Packard Bell Slimview

PIN 1 RED VIDEO RED
PIN 2 GREEN VIDEO GREEN
PIN 3 BLUE VIDEO BLUE
PIN 4 N/C
PIN 5 GROUND HSYNC GND
PIN 6 RED RETURN RED GROUND
PIN 7 GREEN RETURN GREEN GROUND
PIN 8 BLUE RETURN BLUE GROUND
PIN 9 +5 V DDC BLACK
PIN 10 GROUND VSYNC DDC GREEN
PIN 11 N/C
PIN 12 SDA IC DATA ORANGE
PIN 13 HORIZONTAL SYNC WHITE
PIN 14 VERTICAL SYNC YELLOW
PIN 15 SCL IC CLOCK BROWN
